SSCMDRN001PDAA5
SENSOR 1PSID 0.08"" 4.5VManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® SSC series differential pressure sensor, part number SSCMDRN001PDAA5. This sensor offers a ±1 PSI (±6.89 kPa) differential operating pressure range with ±0.25% accuracy. It features an amplified analog voltage output, providing a 0.5 V to 4.5 V signal, and is temperature compensated. The device utilizes dual barbed ports, each accepting a 0.08" (1.93mm) tube, with ports located on opposite sides. Designed for board mount applications, it is supplied in an 8-SMD, J-Lead package with SMD (SMT) tab termination. The operating temperature range is -40°C to 85°C, and it requires a supply voltage of 4.75V to 5.25V. This component is commonly found in industrial automation, HVAC, and medical equipment.
Additional Information
Series: TruStability® SSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-SMD, J-Lead, Dual Ports, Opposite Sides |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | ±1PSI (±6.89kPa) |
| Pressure Type | Differential |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.08"" (1.93mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | ±10PSI (±68.95kPa) |
