SDXL010D4
SENSOR 0.36PSID 0.09"" .025VManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions SDX Series SDXL010D4 is a differential pressure sensor designed for board mount applications. This 6-DIP module offers a pressure range of 0.36 PSI (2.49 kPa) with an operating temperature range from -40°C to 85°C. Featuring temperature compensation and ±1% accuracy, the sensor utilizes a Wheatstone bridge output configuration, providing a 0 mV to 25 mV signal across a 12V supply. The dual port design incorporates male 0.09" (2.29mm) tubes. This component is suitable for various industrial automation and control systems requiring precise differential pressure measurement.
Additional Information
Series: SDXRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | |
| Package / Case | 6-DIP Module |
| Output Type | Wheatstone Bridge |
| Mounting Type | Through Hole |
| Output | 0 mV ~ 25 mV (12V) |
| Operating Pressure | 0.36PSI (2.49kPa) |
| Pressure Type | Differential |
| Accuracy | ±1% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 20V |
| Port Size | Male - 0.09"" (2.29mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 7.23PSI (49.83kPa) |
| Packaging |
