SCCP100GSMTP
SENSOR 100PSIG 0.08"" .225VManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions SCC SMT series SCCP100GSMTP is a surface-mount pressure sensor designed for demanding applications. This vented gauge sensor operates up to 100 PSI (689.48 kPa), with a maximum pressure rating of 150 PSI (1034.21 kPa). It features a 0.08" (2.05mm) male tube port with a barbless port style and an 8-SMD module package. The sensor offers an output range of 85 mV to 225 mV, utilizing a Wheatstone bridge for signal conditioning. With ±1% accuracy and temperature compensation, this component is suitable for industrial, medical, and aerospace applications requiring precise pressure measurement. It operates within a temperature range of -40°C to 125°C.
Additional Information
Series: SCC SMTRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-SMD Module |
| Output Type | Wheatstone Bridge |
| Mounting Type | Surface Mount |
| Output | 85 mV ~ 225 mV |
| Operating Pressure | 100PSI (689.48kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±1% |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | - |
| Port Size | Male - 0.08"" (2.05mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 150PSI (1034.21kPa) |
