HSCSHHN060PDAA5
SENSOR 60PSID 0.16"" 4.5V 4SIPManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® HSC series HSCSHHN060PDAA5 is a ±60 PSI differential pressure sensor with an amplified analog voltage output. This component features a 0.5 V to 4.5 V output range and operates from a 4.75V to 5.25V supply. The sensor is designed for board mounting with a through-hole termination style and a 4-SIP package with dual ports on the same side, utilizing a male 0.16" (3.94mm) barbed tube port. It offers ±0.25% accuracy and is temperature compensated, making it suitable for applications requiring precise differential pressure measurement in environments ranging from -20°C to 85°C. The maximum operating pressure is ±250 PSI. This device is commonly utilized in industrial automation, HVAC systems, and medical equipment.
Additional Information
Series: TruStability® HSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP, Dual Ports, Same Side |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | ±60PSI (±413.69kPa) |
| Pressure Type | Differential |
| Accuracy | ±0.25% |
| Operating Temperature | -20°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.16"" (3.94mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | 4-SIP |
| Port Style | Barbed |
| Maximum Pressure | ±250PSI (±1723.69kPa) |
