ASDXRRX015PGAA5
SENSOR 15PSIG 0.09"" 4.5VManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions ASDX series analog voltage output pressure sensor, part number ASDXRRX015PGAA5. This vented gauge pressure sensor is designed for 15 PSI (103.42 kPa) operating pressure, with a maximum pressure rating of 30 PSI (206.84 kPa). It features a dual 0.5 V to 4.5 V analog voltage output, providing accurate readings across its calibrated range. The sensor incorporates temperature compensation for enhanced performance. The package is an 8-DIP Module with through-hole mounting and PC pin termination, utilizing a male, 0.09-inch (2.31mm) tube port with a barbless style. This component is suitable for board mount applications and operates within a temperature range of -20°C to 105°C. Typical supply voltage is 5V. This sensor is utilized in various industrial and commercial applications requiring precise pressure monitoring.
Additional Information
Series: ASDXRoHS Status: Request inventory verificationManufacturer Lead Time: 41 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-DIP Module |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | 15PSI (103.42kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2% |
| Operating Temperature | -20°C ~ 105°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.09"" (2.31mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 30PSI (206.84kPa) |
