ASDXRRX010NG7A5
SENSOR 0.36PSIG 0.09"" 12BITManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions ASDX Series pressure sensor, part number ASDXRRX010NG7A5. This vented gauge pressure sensor measures 0.36 PSI (2.49 kPa) with a maximum operating pressure of 0.72 PSI (4.96 kPa). It features a dual port design with a male 0.09-inch (2.31mm) tube connection and barbless port style. The sensor provides a 12-bit digital output via I2C, offering ±2% accuracy and temperature compensation. Designed for board mounting, it operates within a 4.75V to 5.25V supply voltage range and an ambient temperature range of -20°C to 105°C. The ASDXRRX010NG7A5 is housed in an 8-DIP module with PC pin termination. This component is commonly utilized in industrial automation, medical devices, and HVAC systems.
Additional Information
Series: ASDXRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-DIP Module |
| Output Type | I2C |
| Mounting Type | Through Hole |
| Output | 12 b |
| Operating Pressure | 0.36PSI (2.49kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2% |
| Operating Temperature | -20°C ~ 105°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.09"" (2.31mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 0.72PSI (4.96kPa) |
