ASDXRRX005PG2A5
SENSOR 5PSIG 0.09"" 12BITManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
The Honeywell Sensing and Productivity Solutions ASDXRRX005PG2A5 is a vented gauge pressure sensor with a 5 PSI operating pressure range. This board mount component features a dual 12-bit output via I2C interface, providing precise digital readings. The sensor is temperature compensated, ensuring stable performance across its operating temperature range of -20°C to 105°C. It utilizes a 0.09" (2.31mm) dual barbless tube port for connection, with a male termination style. Packaged in an 8-DIP module, it is designed for through-hole mounting. This ASDX series device is suitable for applications requiring accurate pressure measurement in industrial and medical equipment.
Additional Information
Series: ASDXRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-DIP Module |
| Output Type | I2C |
| Mounting Type | Through Hole |
| Output | 12 b |
| Operating Pressure | 5PSI (34.47kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2% |
| Operating Temperature | -20°C ~ 105°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.09"" (2.31mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 10PSI (68.95kPa) |
