ASDXRRX001PG7A5
SENSOR 1PSIG 0.09"" 12BITManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions ASDX series pressure sensor, part number ASDXRRX001PG7A5. This vented gauge pressure sensor offers a 1 PSI (6.89 kPa) operating pressure range with a maximum of 2 PSI (13.79 kPa). Featuring a 0.09" (2.31mm) dual barbless male tube port and 8-DIP Module package, it is designed for board mount applications with through-hole mounting. The sensor provides dual 12-bit I2C output and is temperature compensated with an accuracy of ±2%. It operates within a voltage supply range of 4.75V to 5.25V and has an operating temperature range of -20°C to 105°C. This component is utilized in industrial and medical applications.
Additional Information
Series: ASDXRoHS Status: Request inventory verificationManufacturer Lead Time: 48 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 8-DIP Module |
| Output Type | I2C |
| Mounting Type | Through Hole |
| Output | 12 b |
| Operating Pressure | 1PSI (6.89kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2% |
| Operating Temperature | -20°C ~ 105°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.09"" (2.31mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 2PSI (13.79kPa) |
