ABPLLNT010BGAA5
SENSOR 145.04PSIG 0.11"" 4.5V SMDManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Pressure Sensor 145.04PSI (1000kPa) Vented Gauge Male - 0.11"" (2.67mm) Tube 0.5 V ~ 4.5 V 6-SMD Module, No Lead
Additional Information
Series: ABPRoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Tube |
| Package / Case | 6-SMD Module, No Lead |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | 145.04PSI (1000kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 5V |
| Port Size | Male - 0.11"" (2.67mm) Tube |
| Applications | Medical Ventilation |
| Supplier Device Package | 6-SMD |
| Port Style | Barbless |
| Maximum Pressure | 246.56PSI (1700kPa) |
