ABP2MVNT400MG2A3BB
SENSOR 5.8PSIG 0.106"" 14BIT 6SMDManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Pressure Sensor 5.8PSI (40kPa) Gauge Male - 0.106"" (2.69mm) Tube 14 b 6-SMD, J-Lead, Top Port
Additional Information
Series: ABP2RoHS Status: Request inventory verificationManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: BoxDownload Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Box |
| Package / Case | 6-SMD, J-Lead, Top Port |
| Output Type | I2C |
| Mounting Type | Surface Mount |
| Output | 14 b |
| Operating Pressure | 5.8PSI (40kPa) |
| Pressure Type | Gauge |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 110°C |
| Termination Style | J Lead |
| Voltage - Supply | 1.8V ~ 3.6V |
| Port Size | Male - 0.106"" (2.69mm) Tube |
| Applications | Medical Ventilation |
| Supplier Device Package | 6-SMD |
| Port Style | Barbless |
| Maximum Pressure | 29.01PSI (200kPa) |
Request a Quote
