76062-B00000150-01
SWITCH 24PSI SPST-NC 1/8""NPTManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions 76062-B00000150-01, a Series 5000 pressure-activated switch, offers a Single Pole Single Throw Normally Closed (SPST-NC) output. This component operates within a pressure range of 14 PSI to 24 PSI (96.53 kPa to 165.47 kPa), with a maximum pressure rating of 500 PSI (3447.38 kPa). It features a male 1/8" NPT threaded port for secure connection. The operating temperature range is from -40°C to 121°C. This device is suitable for applications in industrial automation, HVAC systems, and automotive controls requiring reliable overpressure or underpressure detection. The component is supplied in bulk packaging.
Additional Information
Series: 5000RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Cylinder, Threaded |
| Output Type | SPST-NC |
| Output | - |
| Operating Pressure | 14PSI ~ 24PSI (96.53kPa ~ 165.47kPa) |
| Pressure Type | Switch |
| Accuracy | - |
| Operating Temperature | -40°C ~ 121°C |
| Termination Style | Screw Terminal |
| Voltage - Supply | - |
| Port Size | Male - 1/8"" (3.18mm) NPT |
| Supplier Device Package | - |
| Port Style | Threaded |
| Maximum Pressure | 500PSI (3447.38kPa) |
Request a Quote
Clients Also Buy
50225C
