142PC15AW
SENSOR 15PSIA 0.2"" 5.33VManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions 140PC Series absolute pressure sensor, part number 142PC15AW. This sensor offers an operating pressure range of 2 PSI to 15 PSI (13.79kPa to 103.42kPa) with an amplified, temperature-compensated analog voltage output from 1V to 5.33V. Featuring a 0.2” (5mm) male tube port and a 3-SIP module package for through-hole mounting, this component is designed for board-mount applications. It exhibits an accuracy of ±0.4% and operates within a supply voltage range of 7V to 16V across an industrial temperature range of -40°C to 85°C. The maximum pressure rating is 45 PSI (310.26kPa). This device is utilized in various industrial automation, medical equipment, and HVAC control systems.
Additional Information
Series: 140PCRoHS Status: Request inventory verificationManufacturer Lead Time: 29 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 3-SIP Module |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 1 V ~ 5.33 V |
| Operating Pressure | 2PSI ~ 15PSI (13.79kPa ~ 103.42kPa) |
| Pressure Type | Absolute |
| Accuracy | ±0.4% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 7V ~ 16V |
| Port Size | Male - 0.2"" (5mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 45PSI (310.26kPa) |
