SEP8505-001
EMITTER IR 935NM 50MA RADIALManufacturer: Honeywell Sensing and Productivity Solutions
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions SEP8205-001 is a through-hole mounted infrared (IR) emitter with a peak wavelength of 935nm. This radial package component operates with a maximum forward current of 50mA and a typical forward voltage of 1.5V. Exhibiting a radiant intensity of a minimum of 0.5mW/cm² at 20mA, this device features a narrow 15° viewing angle for focused IR emission. Designed for a broad operating temperature range of -40°C to 85°C, it is suitable for applications in industrial automation, security systems, and optical sensing. The component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Radial |
| Wavelength | 935nm |
| Mounting Type | Through Hole |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Viewing Angle | 15° |
| Current - DC Forward (If) (Max) | 50mA |
| Radiant Intensity (Ie) Min @ If | 0.5mW/cm² @ 20mA |
