3260-10S3(55)
CONN RCPT 10P 0.031 GOLD SMD R/AManufacturer: Hirose Electric Co Ltd
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
10 Position Receptacle Connector 0.031"" (0.80mm) Surface Mount, Right Angle Gold
Additional Information
Series: 3200RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Board Guide, Shielded |
| Packaging | Tray |
| Connector Type | Receptacle |
| Voltage Rating | 125VAC |
| Current Rating (Amps) | 500mA |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 10 |
| Style | Board to Cable/Wire |
| Operating Temperature | - |
| Contact Type | Center Strip Contact |
| Fastening Type | Latch Holder |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Insulation Color | Black |
| Pitch - Mating | 0.031"" (0.80mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) |
| Contact Finish - Post | Gold |
| Contact Length - Post | - |
| Insulation Height | 0.114"" (2.90mm) |
| Row Spacing - Mating | - |
| Number of Rows | 1 |
