20310500101
SENSOR CURRENT HALL 500A ACManufacturer: HARTING
Categories: Current Sensors
Quality Control: Learn More
The HARTING 20310500101 is a closed-loop Hall effect current sensor designed for accurate AC and DC current measurement up to 500A. This bidirectional, single-channel module features a single pass-through design for simplified integration into power systems. With a high accuracy of ±0.6% and linearity of ±0.1%, it provides precise output signals suitable for demanding applications. The sensor operates over a wide temperature range of -40°C to 85°C and supports a supply voltage from 15V to 24V with a maximum current draw of 24mA. Its ratiometric voltage output and 1µs response time make it ideal for use in industrial automation, power conversion, and electric vehicle charging infrastructure. This component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Single Pass Through |
| Polarization | Bidirectional |
| Sensitivity | - |
| Mounting Type | Panel Mount |
| Output | Ratiometric, Voltage |
| Frequency | 100kHz |
| Accuracy | ±0.6% |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 15V ~ 24V |
| Response Time | 1µs |
| Sensor Type | Hall Effect, Closed Loop |
| Linearity | ±0.1% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 24mA |
| Current - Sensing | 500A |
| Supplier Device Package | - |
| Number of Channels | 1 |
