SSF2320Y
MOSFET, N-CH, SINGLE, 0.8A, 20V,Manufacturer: Good-Ark Semiconductor
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 20 V 800mA (Tc) 312mW (Tc) Surface Mount SOT-523
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-523 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 800mA (Tc) |
| Rds On (Max) @ Id, Vgs | 300mOhm @ 500mA, 4.5V |
| FET Feature | - |
| Power Dissipation (Max) | 312mW (Tc) |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Supplier Device Package | SOT-523 |
| Drive Voltage (Max Rds On, Min Rds On) | 1.2V, 4.5V |
| Vgs (Max) | ±8V |
| Drain to Source Voltage (Vdss) | 20 V |
| Gate Charge (Qg) (Max) @ Vgs | 1 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 75 pF @ 10 V |
