GSFQ4953
MOSFET, P-CH, DUAL, -5.40A, -30VManufacturer: Good-Ark Semiconductor
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 30V 5.4A (Ta) 2W (Ta) Surface Mount 8-SOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 2W (Ta) |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 5.4A (Ta) |
| Input Capacitance (Ciss) (Max) @ Vds | 514pF @ 15V |
| Rds On (Max) @ Id, Vgs | 58mOhm @ 5.3A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 13nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | 8-SOP |
| Grade | - |
| Qualification | - |
