G170P03S2
MOSFET 2P-CH 30V 9A 8SOPManufacturer: Goford Semiconductor
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 30V 9A (Tc) 1.4W (Tc) Surface Mount 8-SOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Digi-Reel®Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Digi-Reel® |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel (Dual) |
| Operating Temperature | -55°C ~ 150°C (Tc) |
| Technology | - |
| Power - Max | 1.4W (Tc) |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 9A (Tc) |
| Input Capacitance (Ciss) (Max) @ Vds | 1786pF @ 4.5V |
| Rds On (Max) @ Id, Vgs | 25mOhm @ 5A, 4.5V |
| Gate Charge (Qg) (Max) @ Vgs | 18nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | 8-SOP |
