G05NP04S
MOSFET 40V 4.5A/10A 8SOPManufacturer: Goford Semiconductor
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 40V 4.5A (Tc), 10A (Tc) 2W (Tc) Surface Mount 8-SOP
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Configuration | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 2W (Tc) |
| Drain to Source Voltage (Vdss) | 40V |
| Current - Continuous Drain (Id) @ 25°C | 4.5A (Tc), 10A (Tc) |
| Input Capacitance (Ciss) (Max) @ Vds | 516pF @ 20V, 520pF @ 20V |
| Rds On (Max) @ Id, Vgs | 41mOhm @ 1A, 10V, 37mOhm @ 10A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 8.9nC @ 10V, 13nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | 8-SOP |
