MCF51MM256CML
IC MCU 32B 256KB FLASH 104MAPBGAManufacturer: Freescale Semiconductor
Categories: Microcontrollers
Quality Control: Learn More
The Freescale Semiconductor MCF51MM series microcontroller, part number MCF51MM256CML, features a 32-bit Coldfire V1 single-core processor operating at 50MHz. This device offers 256KB of FLASH program memory and 32KB of RAM. Connectivity options include CANbus, EBI/EMI, I2C, SCI, SPI, and USB OTG. It is equipped with an 8x16-bit Analog-to-Digital converter and a 1x12-bit Digital-to-Analog converter. Peripherals include LVD, PWM, and WDT. The MCF51MM256CML is housed in a 104-MAPBGA (10x10) surface-mount package and operates within an ambient temperature range of -40°C to 85°C. This component is suitable for applications in automotive, industrial automation, and consumer electronics.
Additional Information
Series: MCF51MMRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 104-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 50MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | Coldfire V1 |
| Data Converters | A/D 8x16b; D/A 1x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, I2C, SCI, SPI, USB OTG |
| Peripherals | LVD, PWM, WDT |
| Supplier Device Package | 104-MAPBGA (10x10) |
| Number of I/O | 69 |
| Programmable | Not Verified |
