MC56F8167VVFE

IC MCU 16B 512KB FLASH 160MAPBGA

Manufacturer: Freescale Semiconductor

Categories: Microcontrollers

Quality Control: Learn More

The Freescale Semiconductor MC56F8167VVFE is a 16-bit microcontroller based on the 56800E core. This device operates at a maximum frequency of 40MHz and features 512KB of FLASH program memory, organized as 256K x 16 bits, alongside 16K x 16 bits of RAM. Connectivity options include EBI/EMI, SCI, and SPI interfaces. It incorporates a 16x12-bit Analog-to-Digital converter and essential peripherals such as Power-on Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). The MC56F8167VVFE is supplied in a 160-MAPBGA (15x15) package, designed for surface mounting, and operates within a voltage range of 2.25V to 3.6V. This component finds application in motor control, industrial automation, and power supply systems. The operating temperature range is -40°C to 105°C (TA).

Additional Information

Series: 56F8xxxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:
Technical Details:
PackagingTray
Package / Case160-BGA
Mounting TypeSurface Mount
Speed40MHz
Program Memory Size512KB (256K x 16)
RAM Size16K x 16
Operating Temperature-40°C ~ 105°C (TA)
Oscillator TypeExternal
Program Memory TypeFLASH
EEPROM Size-
Core Processor56800E
Data ConvertersA/D 16x12b
Core Size16-Bit
Voltage - Supply (Vcc/Vdd)2.25V ~ 3.6V
ConnectivityEBI/EMI, SCI, SPI
PeripheralsPOR, PWM, WDT
Supplier Device Package160-MAPBGA (15x15)
Number of I/O76
ProgrammableNot Verified
