MC56F8027VLD
MC56F8027 - Microcontroller, 16-Manufacturer: Freescale Semiconductor
Categories: Microcontrollers
Quality Control: Learn More
The Freescale Semiconductor MC56F8027VLD is a 16-bit microcontroller based on the 56800E core. This device operates at a maximum frequency of 32MHz and features 32KB of FLASH program memory, organized as 16K x 16 bits, alongside 2KB of RAM. On-chip peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timers (WDT). Connectivity options are extensive, supporting CANbus, I2C, LINbus, SCI, and SPI interfaces. The integrated data converters consist of 16 channels of 12-bit Analog-to-Digital (A/D) conversion and 2 channels of 12-bit Digital-to-Analog (D/A) conversion. This microcontroller is packaged in a 64-LQFP (10x10) surface-mount format and operates within an ambient temperature range of -40°C to 105°C. Its robust feature set makes it suitable for applications in industrial automation, automotive control, and consumer electronics.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 32MHz |
| Program Memory Size | 32KB (16K x 16) |
| RAM Size | 2K x 16 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 56800E |
| Data Converters | A/D 16x12b; D/A 2x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, I2C, LINbus, SCI, SPI |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 64-LQFP (10x10) |
| Number of I/O | 53 |
