LM431CCZXA
IC VREF SHUNT ADJ 0.5% TO92-3Manufacturer: Fairchild Semiconductor
Categories: Voltage Reference
Quality Control: Learn More
Fairchild Semiconductor's LM431CCZXA is an adjustable shunt voltage reference with a precise 2.495V minimum output. This component offers a ±0.5% tolerance and a maximum output voltage of 36V, making it suitable for applications requiring stable voltage regulation. Designed for through-hole mounting in a standard TO-92-3 package, it features a typical temperature coefficient of 50ppm/°C. The device supports a cathode current from 1 mA up to 100 mA. It is commonly employed in power supply regulation, battery charging circuits, and general-purpose voltage references across various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±0.5% |
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Temperature Coefficient | 50ppm/°C Typical |
| Output Type | Adjustable |
| Mounting Type | Through Hole |
| Voltage - Input | - |
| Reference Type | Shunt |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Current - Supply | - |
| Supplier Device Package | TO-92-3 |
| Voltage - Output (Min/Fixed) | 2.495V |
| Noise - 0.1Hz to 10Hz | - |
| Noise - 10Hz to 10kHz | - |
| Current - Cathode | 1 mA |
| Current - Output | 100 mA |
| Voltage - Output (Max) | 36 V |
