FSA7830BUCX
SINGLE-ENDED MULTIPLEXERManufacturer: Fairchild Semiconductor
Categories: Special Purpose
Quality Control: Learn More
Fairchild Semiconductor's FSA7830BUCX is a single-ended analog switch IC designed for high-performance applications. This 1-channel, 8:1 multiplexer, housed in a compact 16-WLCSP (1.78x1.78) package, offers robust functionality for demanding electronic designs. Key features include I2C control for efficient signal routing and an integrated voltage divider, simplifying system architecture. With an operating temperature range of -40°C to 85°C and a supply voltage of 2.7V to 5.5V, the FSA7830BUCX is suitable for a variety of industries including consumer electronics and industrial automation. The surface mount device boasts a maximum on-state resistance of 200 Ohms, ensuring minimal signal degradation.
Additional Information
Series: -RoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | I2C, Voltage Divider |
| Packaging | Bulk |
| Package / Case | 16-UFBGA, WLCSP |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | - |
| On-State Resistance (Max) | 200Ohm |
| -3db Bandwidth | - |
| Supplier Device Package | 16-WLCSP (1.78x1.78) |
| Voltage - Supply, Single (V+) | 2.7V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Channels | 1 |
