FCH47N60N
POWER FIELD-EFFECT TRANSISTOR, 4Manufacturer: Fairchild Semiconductor
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 600 V 47A (Tc) 368W (Tc) Through Hole TO-247
Additional Information
Series: SupreMOS™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-247-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 47A (Tc) |
| Rds On (Max) @ Id, Vgs | 62mOhm @ 23.5A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 368W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Supplier Device Package | TO-247 |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±30V |
| Drain to Source Voltage (Vdss) | 600 V |
| Gate Charge (Qg) (Max) @ Vgs | 151 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 6700 pF @ 100 V |
