1N4305
DIODE GEN PURP 75V 300MA DO35Manufacturer: Fairchild Semiconductor
Categories: Single Diodes
Quality Control: Learn More
Fairchild Semiconductor 1N4305 General Purpose Diode. This through-hole component, housed in a DO-204AH (DO-35) package, offers a maximum DC reverse voltage of 75V and an average rectified current of 300mA. Key specifications include a forward voltage of 850mV at 10mA and a reverse leakage of 100nA at 50V. The capacitance at 0V and 1MHz is 2pF. With a reverse recovery time of 4ns, this diode is classified as fast recovery. Its maximum operating junction temperature is 175°C. This component is suitable for applications in industrial controls, telecommunications, and consumer electronics. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-204AH, DO-35, Axial |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 300mA |
| Supplier Device Package | DO-204AH (DO-35) |
| Operating Temperature - Junction | 175°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 75 V |
| Voltage - Forward (Vf) (Max) @ If | 850 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 100 nA @ 50 V |
