FM25C160UN
IC EEPROM 16KBIT SPI 2.1MHZ 8DIPManufacturer: Fairchild Semiconductor
Categories: Memory
Quality Control: Learn More
Fairchild Semiconductor FM25C160UN is a 16Kbit non-volatile Serial Peripheral Interface (SPI) EEPROM memory device. Organized as 2K x 8, this component operates at a maximum clock frequency of 2.1 MHz. The memory interface utilizes the SPI protocol. The device has a typical write cycle time of 10ms. It is supplied in an 8-DIP (0.300", 7.62mm) package suitable for through-hole mounting and operates within a temperature range of 0°C to 70°C. The supply voltage range is 4.5V to 5.5V. This EEPROM is commonly found in industrial and consumer electronics applications.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Memory Size | 16Kbit |
| Memory Type | Non-Volatile |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Technology | EEPROM |
| Clock Frequency | 2.1 MHz |
| Memory Format | EEPROM |
| Supplier Device Package | 8-DIP |
| Write Cycle Time - Word, Page | 10ms |
| Memory Interface | SPI |
| Memory Organization | 2K x 8 |
| Programmable | Not Verified |
