LM7815CT
IC REG LIN FIXED POS STD REG 15VManufacturer: Fairchild Semiconductor
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Fairchild Semiconductor's LM7815CT is a positive, fixed 15V linear voltage regulator with a 1A output current capability. This TO-220-3 packaged device offers robust protection features including over-temperature and short-circuit protection. It features a quiescent current of 8mA and a maximum input voltage of 35V, with a typical dropout voltage of 2V at 1A. The device demonstrates a PSRR of 70dB at 120Hz. Applications for the LM7815CT are found in industrial, consumer electronics, and telecommunications sectors requiring stable voltage regulation. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-3 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 8 mA |
| Voltage - Input (Max) | 35V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-220-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 15V |
| Control Features | - |
| PSRR | 70dB (120Hz) |
| Voltage Dropout (Max) | 2V @ 1A (Typ) |
| Protection Features | Over Temperature, Short Circuit |
