FMG1G300US60H
IGBT, 300A, 600V, N-CHANNELManufacturer: Fairchild Semiconductor
Categories: IGBT Modules
Quality Control: Learn More
IGBT Module Single 600 V 300 A 892 W Chassis Mount
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 300A |
| NTC Thermistor | No |
| Supplier Device Package | - |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 300 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Power - Max | 892 W |
| Current - Collector Cutoff (Max) | 250 µA |
