FAN5009MPX
HALF BRIDGE BASED MOSFET DRIVERManufacturer: Fairchild Semiconductor
Categories: Gate Drivers
Quality Control: Learn More
Half-Bridge Gate Driver IC Inverting, Non-Inverting 8-MLP (5x6)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-VDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Voltage - Supply | 10V ~ 13.5V |
| Input Type | Inverting, Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 15 V |
| Supplier Device Package | 8-MLP (5x6) |
| Rise / Fall Time (Typ) | 40ns, 20ns |
| Channel Type | Synchronous |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | - |
| Programmable | Not Verified |
