FDMF8704V
IC HALF BRIDGE DRVR 32A PWR88-56Manufacturer: Fairchild Semiconductor
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Half Bridge Driver Synchronous Buck Converters DrMOS 56-Power88™
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit, 5V Regulated Output |
| Packaging | Bulk |
| Package / Case | 56-PowerWFQFN Module |
| Mounting Type | Surface Mount |
| Interface | PWM |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4.5V ~ 5.5V |
| Rds On (Typ) | - |
| Applications | Synchronous Buck Converters |
| Current - Output / Channel | 32A |
| Current - Peak Output | 65A |
| Technology | DrMOS |
| Voltage - Load | 7V ~ 20V |
| Supplier Device Package | 56-Power88™ |
| Fault Protection | Shoot-Through |
| Load Type | Inductive |
