FDZ2554PZ
MOSFET 2P-CH 20V 6.5A 18BGAManufacturer: Fairchild Semiconductor
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Fairchild Semiconductor's FDZ2554PZ is a PowerTrench® series dual P-channel MOSFET array designed for high-efficiency power management applications. This component features a 20V drain-to-source voltage (Vdss) and a continuous drain current (Id) capability of 6.5A at 25°C. The device boasts a low on-resistance (Rds On) of 28mOhm at 6.5A and 4.5V, crucial for minimizing conduction losses. Its logic-level gate drive ensures compatibility with lower voltage control signals. With a maximum power dissipation of 2.1W and an operating temperature range of -55°C to 150°C, this MOSFET array is suitable for demanding environments. The FDZ2554PZ is housed in an 18-BGA (2.5x4) surface-mount package, ideal for space-constrained designs in industries such as consumer electronics and industrial automation. Key parameters include a maximum gate charge (Qg) of 21nC at 4.5V and a maximum input capacitance (Ciss) of 1430pF at 10V.
Additional Information
Series: PowerTrench®RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 18-WFBGA |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel (Dual) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 2.1W |
| Drain to Source Voltage (Vdss) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 6.5A |
| Input Capacitance (Ciss) (Max) @ Vds | 1430pF @ 10V |
| Rds On (Max) @ Id, Vgs | 28mOhm @ 6.5A, 4.5V |
| Gate Charge (Qg) (Max) @ Vgs | 21nC @ 4.5V |
| FET Feature | Logic Level Gate |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Supplier Device Package | 18-BGA (2.5x4) |
