C30902SH-2
SENSOR PHOTODIODE 900NM TO18Manufacturer: Excelitas Technologies
Categories: Photodiodes
Quality Control: Learn More
Excelitas Technologies C30902SH-2 is an avalanche photodiode designed for high-speed optical detection. This component, part of the C30902 series, features a 900nm peak spectral response with a responsivity of 108 A/W at this wavelength. Its fast 500ps response time makes it suitable for demanding applications requiring precise timing. The photodiode operates within a spectral range of 400nm to 1000nm and has a dark current of 15nA typical. Housed in a TO-18 package, it is designed for through-hole mounting. Key specifications include a maximum reverse voltage of 225V and an operating temperature range of -40°C to 70°C. The C30902SH-2 finds application in areas such as optical communication, medical imaging, and industrial sensing.
Additional Information
Series: C30902RoHS Status: RoHS CompliantManufacturer Lead Time: 29 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | TO-18 |
| Wavelength | 900nm |
| Mounting Type | Through Hole |
| Diode Type | Avalanche |
| Operating Temperature | -40°C ~ 70°C |
| Response Time | 500ps |
| Viewing Angle | - |
| Spectral Range | 400nm ~ 1000nm |
| Color - Enhanced | - |
| Responsivity @ nm | 108 A/W @ 900nm |
| Active Area | 0.2mm² |
| Current - Dark (Typ) | 15nA |
| Voltage - DC Reverse (Vr) (Max) | 225 V |
