B57650H0824A001
THERMISTOR NTC 5KOHM BEADManufacturer: EPCOS - TDK Electronics
Categories: NTC Thermistors
Quality Control: Learn More
EPCOS - TDK Electronics NTC Thermistor, part number B57650H0824A001, from the H650 series. This NTC thermistor features a 5k ohm resistance at 25°C with a ±2% tolerance. The component is a glass bead type with a 10.00mm lead wire, designed for free-hanging mounting. Operating within a temperature range of -40°C to 600°C, this device boasts AEC-Q200 qualification, making it suitable for demanding automotive applications. It is supplied in tray packaging.
Additional Information
Series: H650RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Bead, Glass |
| Mounting Type | Free Hanging |
| Operating Temperature | -40°C ~ 600°C |
| B0/50 | - |
| B25/50 | - |
| B25/85 | - |
| B25/100 | - |
| B Value Tolerance | - |
| Resistance in Ohms @ 25°C | 5K |
| Resistance Tolerance | ±2% |
| B25/75 | - |
| Length - Lead Wire | 0.39"" (10.00mm) |
| Grade | Automotive |
| Qualification | AEC-Q200 |
