ME-XU8-4CG-1E-D11E-R2.1
SOM ZYNQ US+ ZU4CG 2GB+2GB PLManufacturer: Enclustra FPGA Solutions
Categories: Microcontrollers, Microprocessor, FPGA Modules
Quality Control: Learn More
The Enclustra FPGA Solutions ME-XU8-4CG-1E-D11E-R2-1 is an embedded module featuring the Xilinx Zynq UltraScale+ MPSoC ZU4CG. This component integrates an ARM® Quad-Core Cortex-A53 processor operating at up to 1.333GHz, alongside a dual-core Cortex-R5 processor and a Mali-400MP2 GPU. Memory configuration includes 1GB of DDR4 RAM and 2GB of DDR4 RAM, with 16GB of onboard flash storage. Designed for demanding applications, this module is suitable for use in industrial automation, medical imaging, and communication infrastructure. Its compact form factor (74.00mm x 54.00mm) and 168-pin connector facilitate integration into various system designs. The operating temperature range is 0°C to 85°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Connector Type | 168 Pin |
| Size / Dimension | 2.910"" L x 2.130"" W (74.00mm x 54.00mm) |
| Speed | 533MHz, 1.333GHz |
| RAM Size | 1GB, 2GB |
| Operating Temperature | 0°C ~ 85°C |
| Module/Board Type | MPU, FPGA Core |
| Core Processor | ARM® Quad-Core Cortex-A53, ARM® Dual-Core Cortex-R5, Mali-400MP2 GPU |
| Co-Processor | - |
| Flash Size | 16GB |
Request a Quote
