690-024-360-900
CONN PLUG USB3.1 TYPEC 24POS SLDManufacturer: EDAC Inc.
Categories: USB, DVI, HDMI Connector Assemblies
Quality Control: Learn More
EDAC Inc. 690 Series USB-C plug connector, part number 690-024-360-900, offers a 24-position solution for USB 3.2 Gen 2 connectivity. This free-hanging (in-line) component is designed for solder termination and supports a current rating of 3A and a voltage rating of 30VAC. The connector facilitates Superspeed+ data transfer rates as per USB 3.1 specifications. It is suitable for applications in data communication, consumer electronics, and industrial automation where high-speed data interfaces are critical. This component is supplied in tray packaging.
Additional Information
Series: 690RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Voltage - Rated | 30VAC |
| Number of Contacts | 24 |
| Connector Type | USB-C (USB TYPE-C) |
| Gender | Plug |
| Current Rating (Amps) | 3A |
| Mounting Type | Free Hanging (In-Line) |
| Shielding | - |
| Operating Temperature | -25°C ~ 85°C |
| Specifications | USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1)) |
| Termination | Solder |
| Ingress Protection | - |
| Mounting Feature | - |
| Number of Ports | 1 |
