ZXRE125ER
IC VREF SHUNT 2% TO92Manufacturer: Diodes Incorporated
Categories: Voltage Reference
Quality Control: Learn More
Diodes Incorporated ZXRE125ER is a shunt voltage reference IC featuring a fixed output of 1.22V with a ±2% tolerance. This device operates with a cathode current ranging from 8 µA up to 20 mA, making it suitable for applications requiring low quiescent current. The ZXRE125ER offers a typical output noise of 60µVrms from 10Hz to 10kHz and a temperature coefficient of 75ppm/°C, ensuring stable performance across its operating temperature range of -40°C to 85°C. Packaged in a standard TO-92 (TO-226-3) through-hole configuration, it is commonly employed in power supplies, battery management systems, and industrial control equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±2% |
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Temperature Coefficient | 75ppm/°C |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Voltage - Input | - |
| Reference Type | Shunt |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Supply | - |
| Supplier Device Package | TO-92 |
| Voltage - Output (Min/Fixed) | 1.22V |
| Noise - 0.1Hz to 10Hz | - |
| Noise - 10Hz to 10kHz | 60µVrms |
| Current - Cathode | 8 µA |
| Current - Output | 20 mA |
