MMBZ15VAL-7-F

TVS DIODE 12VWM 21VC SOT23

Quality Control: Learn More

Diodes Incorporated MMBZ15VAL-7-F is a transient voltage suppressor (TVS) diode designed for robust overvoltage protection. This surface mount device, housed in a SOT-23-3 package (TO-236-3, SC-59), features a 12V reverse standoff voltage and a minimum breakdown voltage of 14.25V. It offers a clamping voltage of 21V at a peak pulse current (Ipp) of 1.9A (10/1000µs). With a peak pulse power of 40W, the MMBZ15VAL-7-F is suitable for general-purpose applications across various industries requiring protection against transient surges. The operating temperature range is -65°C to 150°C (TJ). The component is supplied on a Tape & Reel (TR) for automated assembly.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	TO-236-3, SC-59, SOT-23-3
Mounting Type	Surface Mount
Type	Zener
Operating Temperature	-65°C ~ 150°C (TJ)
Applications	General Purpose
Capacitance @ Frequency	-
Current - Peak Pulse (10/1000µs)	1.9A
Voltage - Reverse Standoff (Typ)	12V
Supplier Device Package	SOT-23-3
Unidirectional Channels	2
Voltage - Breakdown (Min)	14.25V
Voltage - Clamping (Max) @ Ipp	21V
Power - Peak Pulse	40W
Power Line Protection	No
