AH3362Q-SA-7
MAGNETIC SWITCH UNIPOLAR SOT23-3Manufacturer: Diodes Incorporated
Categories: Switches (Solid State)
Quality Control: Learn More
Diodes Incorporated AH3362Q-SA-7 is a unipolar Hall effect switch designed for automotive applications. This electronic component features an open-drain output and operates with a supply voltage range of 3V to 28V, drawing a maximum of 4mA. The device is qualified to AEC-Q100 standards, ensuring reliability in demanding environments. Its sensing capabilities include a 3mT trip point and a 2mT release point, specifically responding to the south pole of a magnet. The AH3362Q-SA-7 is housed in a SOT-23-3 package, suitable for surface mounting. It is supplied on tape and reel for automated assembly. The operating temperature range is -40°C to 150°C. This component is utilized in automotive systems such as seat position sensing and door latch detection.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Output Type | Open Drain |
| Polarization | South Pole |
| Mounting Type | Surface Mount |
| Function | Unipolar Switch |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Voltage - Supply | 3V ~ 28V |
| Technology | Hall Effect |
| Sensing Range | 3mT Trip, 2mT Release |
| Current - Output (Max) | 60mA |
| Current - Supply (Max) | 4mA |
| Supplier Device Package | SOT-23-3 |
| Test Condition | 25°C |
| Grade | Automotive |
| Qualification | AEC-Q100 |
