PI3USB14QEX
IC USB SWITCH DUAL 4X1 16QSOPManufacturer: Diodes Incorporated
Categories: Special Purpose
Quality Control: Learn More
Diodes Incorporated PI3USB14QEX is a dual 2-channel USB 2.0 switch IC featuring 4:1 multiplexer/demultiplexer circuitry. This 16-QSOP packaged component offers a -3dB bandwidth of 815MHz and a maximum on-state resistance of 8 Ohms. Designed for surface mounting, it operates with a single 3.3V supply and a temperature range of -40°C to 85°C. The PI3USB14QEX is utilized in applications requiring high-speed USB switching, commonly found in consumer electronics, computing, and communication systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | USB 2.0 |
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | USB |
| On-State Resistance (Max) | 8Ohm |
| -3db Bandwidth | 815MHz |
| Supplier Device Package | 16-QSOP |
| Voltage - Supply, Single (V+) | 3.3V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Channels | 2 |
