ZXMN10A08E6QTA
MOSFET BVDSS: 61V~100V SOT26 T&RManufacturer: Diodes Incorporated
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 100 V 1.5A (Ta) 1.1W (Ta) Surface Mount SOT-26
Additional Information
Series: Automotive, AEC-Q101RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 1.5A (Ta) |
| Rds On (Max) @ Id, Vgs | 250mOhm @ 3.2A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 1.1W (Ta) |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Supplier Device Package | SOT-26 |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 7.7 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 405 pF @ 50 V |
