SDM2A40CSP-7B
DIODE SCHOTT 40V 2A X3-WLB1608-2Manufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diode 40 V 2A Surface Mount X3-WLB1608-2
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 2-XDFN |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 14 ns |
| Technology | Schottky |
| Capacitance @ Vr, F | 81pF @ 5V, 1MHz |
| Current - Average Rectified (Io) | 2A |
| Supplier Device Package | X3-WLB1608-2 |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 470 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 100 µA @ 40 V |
