SDM1100LP-7
DIODE SCHOTT 100V 1A U-DFN2020-2Manufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diode 100 V 1A Surface Mount U-DFN2020-2
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Digi-Reel®Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Digi-Reel® |
| Package / Case | 2-UDFN |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | 40pF @ 5V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | U-DFN2020-2 |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 770 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 350 µA @ 100 V |
| Qualification | AEC-Q101 |
