S3D-13
DIODE GEN PURP 200V 3A SMCManufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diodes Incorporated S3D-13 is a general-purpose rectifier diode designed for surface-mount applications. This component offers a maximum repetitive reverse voltage of 200V and an average rectified forward current capability of 3A. Featuring a standard recovery time exceeding 500ns for currents greater than 200mA, the S3D-13 exhibits a typical forward voltage drop of 1.15V at 3A. Its reverse leakage current is rated at 10 µA at 200V. The diode is housed in a DO-214AB (SMC) package and operates within a junction temperature range of -65°C to 150°C. The S3D-13 finds application in power supply rectification, switching power supplies, and general-purpose rectification across various industrial and consumer electronics sectors. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Capacitance @ Vr, F | 40pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 3A |
| Supplier Device Package | SMC |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.15 V @ 3 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 200 V |
