DSR8V600
DIODE GEN PURP 600V 8A TO220ACManufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diodes Incorporated DSR8V600 from the DIODESTAR™ series is an 8A general-purpose rectifier diode with a 600V reverse voltage rating. This through-hole component, housed in a TO-220AC package, features a fast recovery time of 23 ns, suitable for applications requiring efficient switching. The forward voltage drop is specified at a maximum of 3.2V at 8A, with a low reverse leakage current of 20 µA at 600V. Operating across a junction temperature range of -65°C to 175°C, this diode is utilized in power supply circuits, industrial automation, and automotive applications.
Additional Information
Series: DIODESTAR™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 23 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 8A |
| Supplier Device Package | TO-220AC |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 3.2 V @ 8 A |
| Current - Reverse Leakage @ Vr | 20 µA @ 600 V |
