DSC06A065FP
SILICON CARBIDE RECTIFIER ITO-22Manufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diodes Incorporated DSC06A065FP is a Silicon Carbide Schottky rectifier, designed for high-performance applications. This through-hole component, packaged in an ITO-220AC (Type WX) case, offers a repetitive peak reverse voltage of 650 V and a continuous average rectified forward current of 6 A. Featuring a low forward voltage drop of 1.5 V at 6 A, it contributes to improved system efficiency. The device exhibits a reverse leakage current of 200 µA at its maximum reverse voltage. Its fast switching characteristics, with a speed classified as Fast Recovery =< 500ns, > 200mA (Io), make it suitable for demanding power electronic designs. The operating junction temperature range is -55°C to 175°C. This rectifier is commonly utilized in power factor correction, switch-mode power supplies, and electric vehicle charging systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 Full Pack, Isolated Tab |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | SiC (Silicon Carbide) Schottky |
| Capacitance @ Vr, F | 273pF @ 100mV, 1MHz |
| Current - Average Rectified (Io) | 6A |
| Supplier Device Package | ITO-220AC (Type WX) |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 6 A |
| Current - Reverse Leakage @ Vr | 200 µA @ 650 V |
