B130B-13
DIODE SCHOTTKY 30V 1A SMBManufacturer: Diodes Incorporated
Categories: Single Diodes
Quality Control: Learn More
Diodes Incorporated B130B-13 is a 30V, 1A Schottky barrier rectifier in a DO-214AA (SMB) package. This surface-mount device features a low forward voltage of 500mV at 1A and a reverse leakage current of 500µA at 30V. The capacitance at 4V and 1MHz is 110pF. The operating junction temperature range is -65°C to 150°C. This component is suitable for power supply rectification, reverse polarity protection, and switching applications across various industrial sectors. The device is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | 110pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | SMB |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Voltage - Forward (Vf) (Max) @ If | 500 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 30 V |
