PT7C4337ACSE
IC RTC CLK/CALENDAR I2C 16SOICManufacturer: Diodes Incorporated
Categories: Real Time Clocks
Quality Control: Learn More
Diodes Incorporated PT7C4337ACSE is a high-precision Clock/Calendar IC offering I2C, 2-Wire serial interface capabilities. This component features a 16-SOIC (0.295", 7.50mm Width) package suitable for surface mounting. Its timekeeping current is exceptionally low, drawing a maximum of 0.8µA at supply voltages between 1.3V and 1.8V. The device supports both HH:MM:SS (12/24 hr) time and YY-MM-DD-dd date formats, incorporating features such as alarm functions, leap year compensation, and square wave output. Operating across a wide temperature range of -40°C to 85°C, the PT7C4337ACSE is designed for applications requiring accurate timekeeping and calendar functions in automotive, industrial, and consumer electronics. The supply voltage range is 1.8V to 5.5V.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Alarm, Leap Year, Square Wave Output |
| Packaging | Tube |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | - |
| Interface | I2C, 2-Wire Serial |
| Type | Clock/Calendar |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.8V ~ 5.5V |
| Time Format | HH:MM:SS (12/24 hr) |
| Date Format | YY-MM-DD-dd |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply, Battery | - |
| Current - Timekeeping (Max) | 0.8µA @ 1.3V ~ 1.8V |
| Programmable | Not Verified |
