ZXMS6008FFQ-7
LOW SIDE INTELLIFET SOT23F T&R 3Manufacturer: Diodes Incorporated
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:1 N-Channel 1.1A SOT-23F
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-3 Flat Leads |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | - |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Output Configuration | Low Side |
| Rds On (Typ) | 500mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 60V |
| Voltage - Supply (Vcc/Vdd) | 0V ~ 5.5V |
| Current - Output (Max) | 1.1A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | SOT-23F |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit, UVLO |
| Grade | Automotive |
| Qualification | AEC-Q100 |
