AP2552W6-7
IC PWR SWITCH P-CHAN 1:1 SOT26Manufacturer: Diodes Incorporated
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Diodes Incorporated AP2552W6-7 is a high-side P-channel power switch designed for general-purpose applications. This SOT-26 packaged device delivers a continuous output current of up to 2.1A, featuring an on-resistance (Rds On) of 70mOhm typical. The AP2552W6-7 incorporates robust fault protection mechanisms, including adjustable current limiting, over-temperature shutdown, and reverse current protection, alongside undervoltage lockout (UVLO). Its integrated features include load discharge functionality and a status flag for monitoring. The device operates within a load voltage range of 2.7V to 5.5V and a junction temperature range of -40°C to 125°C. This component is commonly utilized in automotive and industrial applications where reliable power distribution and load management are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 54 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Load Discharge, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 |
| Output Type | P-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 70mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 2.1A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | SOT-26 |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, Reverse Current, UVLO |
